NanoLensConnection
A Revolution in Fiber Optic Connections
In a world where every bit of data matters and connection reliability is crucial, Nanores proudly presents NanoLensConnection – a breakthrough technology that redefines standards in fiber optics. Our innovative service offers unmatched precision and performance, ensuring minimal signal loss and maximum connection durability, even in the most demanding environments.
NanoLensConnection is not just a connection. It is an advanced solution that, by creating a Fresnel micro-lens directly on the fiber optic forehead, eliminates the need for external optical components, significantly simplifying the connector design and increasing its reliability.
Choose NanoLensConnection to ensure your optical systems have a future where reliability and performance go hand in hand with innovation.
Application
NanoLensConnection connectors are used in modern data transmission systems. Thanks to low signal loss and high mechanical resistance, they are ideal for installation conditions where reliability and durability of fiber optic connections are important. They also enable easy and quick network reconfiguration while maintaining transmission parameters.
In industry—particularly in automation, robotics, and monitoring systems—optical fibers are increasingly being used to transmit control signals, sensor data, or vision inspection systems. NanoLensConnection provides resistance to vibration, dust, and breakage, making it ideal for harsh industrial environments.
Optical solutions in vehicles require ultra-resistant, durable, and compact connectors. NanoLensConnection connectors meet these requirements thanks to their high mechanical strength and compact form, integrating the lens directly onto the fiber. They are the ideal solution for autonomous vehicles, electromobility, and intelligent transport systems.
In medical equipment, optical fibers are used to transmit light and data in devices such as endoscopes, optical tomographs, imaging systems, and disposable sensors. Thanks to its precise beam focusing and customizable diameter, NanoLensConnection technology can be adapted to the needs of equipment requiring high reliability and small dimensions.
Use of technology
Technological advantage
🔹NanoLens directly on the optical fiber – no additional optical components, integrated directly into the fiber tip. 🔹PFIB (Plasma Focused Ion Beam) technology – allows for high surface quality without compromising the optical properties of the glass. 🔹Top-down fabrication – precise control of lens shape and focal length while maintaining microscale tolerance.
Performance and durability
🔹Low transmission attenuation (<1 dB) – effective transmission even with slight core mismatches. 🔹High return loss (>40 dB) – reduction of interference and signal reflections. 🔹High mechanical resistance (up to 200 N) – works well in harsh industrial environments. 🔹Over 1000 mating cycles – up to twice as many as typical premium connectors. 🔹No components that loosen over time – durable construction even with frequent use.
Versatility and flexibility
🔹Possibility of connecting different types of optical fibers – both single-mode and multimode, with different core diameters (9–65 µm). 🔹Compatibility with simplex and duplex systems – for unidirectional and bidirectional transmission. 🔹No need for precise core alignment – thanks to a lens that focuses and redirects the light beam. 🔹Customization options – for OEM customers and system integrators.
Savings and economy
🔹Lower servicing and replacement costs – thanks to a higher number of cycles and connection durability. 🔹Reduced inventory of optical components – one solution instead of many types of connectors. 🔹Fewer assembly errors – thanks to the simplified mechanical design of the connector. 🔹Lower signal loss = lower costs of signal amplification in transmission paths.
Technical parameters
| Feature | Value | Advantage |
|---|---|---|
| Attenuation | < 1 dB | Minimal transmission losses |
| Reflected attenuation | > 40 dB | Signal stability and quality |
| Connect-disconnect cycle | ≥ 1000 | Longevity and reliability |
| Diameters of supported cores | 9 µm – 65 µm | Versatility |
| Mechanical resistance | up to 200 N | Durability even in harsh conditions |
| Price (depending on diameter): | from 3000 zł | A market alternative to the premium class |
How to order NanoLensConnection connectors?
The ordering process begins with a consultation with our specialist, during which we discuss the details of the project and determine the technical requirements. We then prepare a detailed quote and implementation schedule.
Contact our expert using the form below:
